Description

ALIGN TB60 Top Combo (RH60E21XT)

600-class flybarless electric helicopter running on 12S power (two 6S LiPo packs), with belt-driven tail.

• Main blades: 600 mm carbon (1339 mm rotor diameter)
• Tail blades: 95 mm carbon (253 mm tail rotor diameter)
• Power: 2 × 6S LiPo, 2600–4600 mAh (3300 mAh suggested)
• Gear ratio: 7.89:1:5.04, approx. 2400 max head speed
• Top Combo includes: 750MX 480KV motor, RCE-BL130A ESC, DS830M/DS835M brushless servos, carbon main and tail blades (flybarless unit not included)
• Weight: approx. 2.9 kg without batteries

Model history

• Released: Mid-2023
• Status: Current

Manual covers assembly, setup and parts list. Original release edition; see the September 4, 2023 revision for the latest TB60 manual.
