Find the latest build information for the T-REX 470LM Dominator Super Combo. We walk you through the build process with tips, tricks, and manual corrections. We are in the process of completing final video's which will be available over the next couple of days.
Please, if you find a mistake in any of the video’s, the manual, or just have a great suggestion or request send an email to
Manual Mistakes
Mistakes found in the manual which was included in the 470Lm Super Combo. Align is aware of these errors and is updating the manual. You will find a link to the latest pdf version below.
Page 6: Bottom left of manual reads, “Make sure the linkage rod M2 is completely fastened with main rotor grip arm integrated control link and apply a little amount of t22 thread lock to avoid any vibration and loose fitted during flight and cause it breaks. Correction: DO NOT APPLY T22 to the main rotor grip arm or any plastic parts. Thread lock for metal on metal application.
Page 11: This page shows to install the ball on the middle hole of the servo arm. Tail authority is IMPROVED by installing ball on the inner hole (closest to the servo horn center screw). Online manual will reflect this change.
Page 12: This page shows two main shaft spacers are included (0.2 and 0.1 thick); however, only one was included in parts bag 470HZ3. I did not measure the thickness and the one included work fine. (44.15 min. mark of video)
Current Updated Manual Download Link
www.align.com.tw/ManuaLib/Heli/Helicopter/RH47E01XT.pdf
T-REX 470LM Dominator Build Rotor Head Video Part 1 of 5
This 470LM build video covers pages 1 to 6 (Rotor Head Assemble) of the Instruction Manual. Step by Step instructions for assembling Align's NEW T-REX 470LM Dominator Combo Model.
TREX 470LM Dominator Build Frame Assembly Video Part 2 of 5
This 470LM build video covers pages 7 to 8 (Frame Assembly) of the Instruction Manual. Step by Step instructions for assembling Align's NEW T-REX 470LM Dominator Combo Model.
REX 470LM Dominator Build Electronics and Tail Video Part 3 of 5
This 470LM build video covers pages 9 to 12 (Rotor Head Assemble) of the Instruction Manual. Step by Step instructions for assembling Align's NEW T-REX 470LM Dominator Combo Model.
REX 470LM Dominator Build Tail Video Part 4 of 5
This 470LM build video covers pages 13 to 17 (Tail Assemble) of the Instruction Manual. Step by Step instructions for assembling Align's NEW T-REX 470LM Dominator Combo Model.
REX 470LM Dominator Build Tail Video Part 5A of 5
This 470LM build video covers pages 18 to 19 (Electronic Placement) of the Instruction Manual. Step by Step instructions for assembling Align's NEW T-REX 470LM Dominator Combo Model.
